Product Highlights
Description
- RJ45 Cat.6 Tool-Free Modular Plug / Termination Plug Connector
- Superior one-piece die-cast fast field installation RJ45 plug protects data transmission from crosstalk
- With wire load bar, RJ45 plug installation becomes easier and faster
- Suitable for 23 to 26 AWG stranded UTP cables
- Compatible with PoE Type III 60W and Type IV 100W applications
Technical Details
- Extractor: PC, UL 94V-2
- Housing: PC
- RJ45 plug housing: PC, UL 94V-2
- RJ45 plug contact material: Phosphor bronze with 100 micron-inch nickel plated
- Contact finish: 50 micron-inch gold plated on plug contact area
- Grounding contact: Zinc die-casting with nickel plated
- Wire management bar: PC, UL 94V-2
- IDC housing: PC and Glass Fiber, UL 94V-2
- IDC terminal: titanium copper with tin plated
- Dust cap: PE, black color
- PCB: UL 94V-0
